Adding a Spa to an Existing Pool in Flower Mound, TX
Flower Mound Pool Resurfacing can add a spa to an existing pool in Flower Mound, Texas, with new structural work and plumbing and no need to demolish the pool. Typical Dallas–Fort Worth prices in 2025 put an in-ground spa added to an existing pool at $18,000 to $35,000, depending on its size and complexity, and the work is best planned alongside a resurfacing so the pool is drained only once.
Request a free estimate, any time. We'll talk through the spa’s size and seating, the heater and cover, the Town permit, and whether the pool should get its new finish in the same drain-down.
Call or request a free estimate any time, 24/7
No charge · answered 24/7
Get free estimates
Spa rules in the International Swimming Pool and Spa Code
Depth, seats and floor
A permanent residential spa follows the code’s spa chapter, less a few sections written for public spas, plus its general chapter, and that chapter governs the spa’s design, installation, construction and repair. Water may be no deeper than 4 feet from the design waterline, except in special-purpose spas the authority approves; any seat or sitting bench may sit no deeper than 28 inches; and the floor may slope no more than 1 unit in 12.
Heat, heaters and covers
The code caps the incoming makeup water at 104°F and the water at the heater’s return outlet at 140°F, and it asks for a way to monitor the water temperature. An electric heater needs a readily accessible on-off switch at or within 3 feet of it, besides the circuit breaker, and a gas-fired heater may not have a continuously burning pilot. Outdoor heated pools and outdoor permanent spas need a vapor-retardant cover or another approved means, unless a heat pump or solar supplies more than 70 percent of the heat over a season.
Suction fittings and skimmers
Spa suction fittings must be listed to APSP 16 and sized and installed to the maker’s specifications, and a spa may not be used while a suction outlet cover is missing, damaged, broken or loose. Where skimmers are a spa’s only overflow system, the code calls for one per 150 square feet of spa surface, against one per 800 square feet for a residential pool.
Flower Mound Pool Resurfacing will talk through a spa layout that fits your pool and yard.
Call or request a free estimate any time, 24/7.
(469) 526-3886Building the spa onto the pool
Structure and insulation
Asked about reshaping a spa’s interior and moving its drains and jets, the American Shotcrete Association said it can’t advise on the structure of a spa remodel and suggested a local engineer who knows pools and spas, adding that shotcrete overlays and patches succeed or fail on the surface preparation. For heat, it describes two ways to insulate a concrete spa: foam glued or sprayed onto the outside of the shell after it is shot, or an insulated concrete form on one side, with foam 1 to 4 inches thick. A spa can also be one part of a wider pool remodeling project with a new finish, tile and coping.
Wiring, gas and plumbing
In Flower Mound, pool, spa and hot tub electrical work is done by a licensed electrician authorized to work in the town and plumbing by a licensed plumber with the same standing, and electrical and plumbing work each carry their own Town permit. The Town’s pool permit packet, written for new pools, wants the electric provider, Oncor or CoServ, to stamp the plans and asks for a gas line diagram when a heater is planned; at the pool final, inspectors check GFCI protection on the pool lights and bonding on any metal within 5 feet of the pool walls.
Covers and barriers
A spa or hot tub with a lockable safety cover that meets ASTM F1346 is exempt from the barrier sections of the Town’s amended code; the pool beside it still falls under the Town’s barrier rules. An existing spa that only needs a new interior is a different job, covered under spa resurfacing.
Ask Flower Mound Pool Resurfacing for a free estimate on adding a spa.
Call or request a free estimate any time, 24/7.
(469) 526-3886
Permits for a spa addition in Flower Mound
The Town permits every spa and hot tub, even a self-contained one, since its electrical or plumbing work has to be inspected. Its fee schedule effective October 1, 2026 lists $250 for a spa permit and a $120 plan review that is credited toward the permit once approved. A spa follows the pool’s placement rules: no front yard, no easement, and a gap of at least five feet to the side and rear property lines. Plan review times, inspections and what an HOA may ask for are in the guide to pool remodel permits and HOA approval. In Bridlewood, the HOA's 2023 design guidelines limit each lot to a single spa or hot tub, kept to side and rear yards, with its equipment screened by a cedar fence or shrubs on all sides.
Next door, Copper Canyon, where 38.4% of homes were built before 1990 in 2020–2024 survey estimates, lists building or repairing a swimming pool or spa among the projects that need a Town permit, and our page on adding a spa to a pool in Copper Canyon covers that town. Flower Mound Pool Resurfacing will lay out the permit steps before work starts.
Call or request a free estimate any time, 24/7.
(469) 526-3886What adding a spa to a pool costs
- In-ground spa added to an existing pool (DFW, 2025)
- $18,000–$35,000
- Hot tub added in a Dallas pool remodel (2026)
- $2,000–$25,000
- Hot tub added to an existing pool, average (national, 2025)
- about $17,000
- Spa area as a pool addition, installed (national, 2025)
- $6,500–$15,000
- For comparison: a spa built with a new DFW pool (2026)
- $15,000–$30,000
Published Dallas–Fort Worth, Dallas and national figures, not our prices. A spa is priced after a site visit.
The Dallas remodel figure doesn’t say what kind of hot tub it prices. Ask whether a quote includes the Town’s $250 spa permit and $120 plan review. Scuppers, sheer descents and other effects are priced on the page about pool water features and waterfalls.
Call or request a free estimate any time, 24/7.
(469) 526-3886Adding a spa questions and answers
Can you add a spa to an existing inground pool?
Yes. Dallas–Fort Worth figures from 2025 describe it as structural work and new plumbing without demolishing the pool, best timed with a resurfacing so the pool is drained once. For the structure, the American Shotcrete Association points owners to a local engineer who knows pools and spas. Flower Mound Pool Resurfacing can look at your pool and talk through where a spa would fit.
How much does it cost to add a spa to an existing pool?
Typical Dallas–Fort Worth prices in 2025 run $18,000 to $35,000 for an in-ground spa added to an existing pool, depending on its size and complexity. National averages from 2025 put adding a hot tub to an existing pool at about $17,000 including labor.
How much does a hot tub add to the cost of a pool?
In a new Dallas–Fort Worth pool, one 2026 builder’s guide puts spa or hot tub integration at $5,000 to $20,000, and another 2026 guide puts an integrated spa at $15,000 to $30,000. Both are prices for a spa built with the pool, not one added later.
Does a spa added to a pool need a permit in Flower Mound?
Yes. Hot tubs and spas need a Town permit, $250 under the fee schedule effective October 1, 2026, with a $120 plan review credited toward it, and the electrical and plumbing work need their own permits. Confirm the details with the Town’s Building Inspections.
How hot can a spa be?
The International Swimming Pool and Spa Code caps the incoming makeup water at 104°F and the water at the heater’s return outlet at 140°F. At public spas, the code’s required signs tell users to check the temperature before each use and not to enter if it is above 104°F.
Get a free estimate to add a spa
Flower Mound Pool Resurfacing answers calls and estimate requests 24/7. Tell us about the pool, where you would like the spa, and whether the pool needs a new finish too.
